PDF.js Deep Dive from Demo 9: Network Streams and Range Requests

Introduction

Article 7 reached GetReader: the worker requests PDF bytes from the main thread through PDFWorkerStream, and the main thread creates a PDFFetchStreamReader to initiate the fetch. Two questions remained:

1. How is the isRangeSupported value returned by ReaderHeadersReady calculated?
2. When the worker needs a particular byte range, when does GetRangeReader actually result in an HTTP Range request?

This article continues with the demo's actual values:

url = "https://assets-blog.streampdf.com/PDF32000_2008.pdf";
rangeChunkSize = 65536; // 64KB
disableRange = false;
disableStream = false;
disableAutoFetch = false;

The demo server's response has already confirmed Range support. This article therefore follows the path of progressive full streaming in parallel with on-demand Range requests, rather than downloading the entire file in one go or cancelling the full stream and issuing only Range requests.

For the four network stream implementations and the complete validation function, see the network stream source walkthrough. This article focuses only on the PDFFetchStream → PDFWorkerStream → NetworkPdfManager → ChunkedStreamManager call chain actually taken by the demo.

ReaderHeadersReady: Range Capability Detection

Lines 37-146: The Full Reader Sends a Regular GET First

After the worker's PDFWorkerStreamReader sends GetReader, the main thread executes:

this.#fullReader = this.#networkStream.getFullReader();

The demo's networkStream is a PDFFetchStream, so this creates a PDFFetchStreamReader. Its constructor issues the first request:

fetch(url, {
  method: "GET",
  headers, // no Range header
  signal: this._abortController.signal,
  mode: "cors",
  credentials: "same-origin", // withCredentials = false
  redirect: "follow",
});

This is an ordinary full-file GET. PDF.js does not yet know whether the server supports Range, so it must obtain the response headers first.

Lines 79-146: Response Headers Provide the Basis for Detection

The key response headers for the demo URL are:

HTTP/2 200
content-type: application/pdf
content-length: 22491828
accept-ranges: bytes

The response has no content-encoding, so the validation logic treats it as identity.

PDFFetchStreamReader then obtains:

this._reader = response.body.getReader();
this._contentLength = 22491828;
this._isStreamingSupported = true;  // !disableStream
this._isRangeSupported = false;     // awaiting validation

response.body.getReader() means the full response can be read in chunks. Whether to keep this stream depends on the combination of range capability and disableStream.

Lines 51-108: All Five Checks Pass

validateRangeRequestCapabilities determines _isRangeSupported. Substituting the demo's actual response gives:

Therefore:

this._contentLength = 22491828;
this._isRangeSupported = true;

The second check is where the 64KB setup from Article 2 first takes effect: only when the file is larger than two chunks is it worthwhile to abandon a simple full download and enable range management.

Note that disableRange = false only permits the use of range requests; it does not force them. The actual capability is determined by the response headers and file length.

Lines 51-2700: The Demo Does Not Cancel the Full Stream

In the fetch implementation, the full reader is cancelled only if the following condition holds:

if (!this._isStreamingSupported && this._isRangeSupported) {
  this.cancel(new AbortException("Streaming is disabled."));
}

In the demo:

this._isStreamingSupported = true;
this._isRangeSupported = true;

!this._isStreamingSupported evaluates to false, so the stream is not cancelled. The full stream continues delivering data from the beginning of the file toward the end; subsequent Range requests fill the regions that the parser needs immediately but that the full stream has not yet reached.

Finally, the reader resolves headersReady. The main thread's ReaderHeadersReady handler returns:

{
  isStreamingSupported: true,
  isRangeSupported: true,
  contentLength: 22491828,
}

When both capability values are true, the main thread also clears fullReader.onProgress; subsequent download progress is instead reported by the worker's DocProgress based on the chunks already loaded.

NetworkPdfManager: Splitting the File into 344 Chunks

Lines 228-253: The Worker Selects a Manager Based on the Capability Values

After the worker-side PDFWorkerStreamReader receives the three capability values above, it resolves its own headersReady. getPdfManager enters the range branch:

pdfManagerArgs.source = pdfStream;
pdfManagerArgs.length = 22491828;
pdfManagerArgs.disableAutoFetch ||= fullReader.isStreamingSupported;
// false ||= true → true

newPdfManager = new NetworkPdfManager(pdfManagerArgs);

If the server did not support range requests, NetworkPdfManager would not be created here; the worker would wait for the full stream to finish and then use the complete bytes to create a LocalPdfManager. The demo uses the network manager instead.

There is another easy-to-miss assignment:

disableAutoFetch = true;

It does not disable the full stream. Instead, it prevents ChunkedStreamManager from automatically prefetching other missing chunks after each chunk arrives. Because the demo's progressive full stream is already continuously supplying data, automatic Range prefetching would cause duplicate downloads.

Lines 21-270: Splitting 22,491,828 Bytes into 344 Chunks

NetworkPdfManager creates a ChunkedStreamManager, which initializes:

this.chunkSize = 65536;
this.stream = new ChunkedStream(22491828, 65536, this);
this.disableAutoFetch = true;

ChunkedStream preallocates the complete address space and calculates the chunk count:

this.bytes = new Uint8Array(22491828);
this.numChunks = Math.ceil(22491828 / 65536); // 344
this._loadedChunks = new Set();               // initially empty
this.progressiveDataLength = 0;

The last chunk is not a full 64KB:

bytes is only a container of the full file length; it does not mean the data has been downloaded. _loadedChunks records which regions actually contain bytes.

Lines 91-460: Two Data Channels Feed the Same Chunk Store

The demo has two data supply paths at the same time:

When data from the full stream reaches NetworkPdfManager:

sendProgressiveData(chunk) {
  this.streamManager.onReceiveData({ chunk }); // no begin
}

ChunkedStreamManager sees begin === undefined and writes it as progressive data:

const position = stream.progressiveDataLength;
stream.onReceiveProgressiveData(chunk);
// writes bytes[position...], updates progressiveDataLength and _loadedChunks

Range data carries an explicit begin and goes through stream.onReceiveData(begin, chunk). Both paths ultimately share the same bytes and _loadedChunks, so the parser does not need to know which channel supplied the data.

How Missing Bytes Become Range Requests

Lines 135-155: The Parser Throws MissingDataException When It Reads a Missing Chunk

While parsing, PDFDocument reads bytes through ChunkedStream. Regions already covered by the progressive full stream can be read directly:

ensureRange(begin, end) {
  if (end <= this.progressiveDataLength) {
    return;
  }
  // otherwise check _loadedChunks chunk by chunk
}

If the target region extends beyond the progressive data, it still does not access the network immediately. Instead, it checks _loadedChunks first—the required region may already have arrived through another Range request.

If data is still missing, it throws:

throw new MissingDataException(begin, end);

This exception identifies the byte range currently needed by the parser; it is not yet an HTTP request. For example, parsing the xref requires the end of the file while the progressive stream has reached only the beginning, producing this exception.

Lines 211-225: NetworkPdfManager Fills the Gap and Retries the Original Operation

NetworkPdfManager.ensure is one of the unified entry points for document-level reads:

async ensure(obj, prop, args) {
  try {
    const value = obj[prop];
    if (typeof value === "function") {
      return await value.apply(obj, args);
    }
    return value;
  } catch (ex) {
    if (!(ex instanceof MissingDataException)) {
      throw ex;
    }
    await this.requestRange(ex.begin, ex.end);
    return this.ensure(obj, prop, args);
  }
}

It catches only MissingDataException:

1. Requests the missing range;
2. Waits for all chunks corresponding to the range to arrive;
3. Re-executes the original obj[prop];
4. Rethrows other exceptions as usual, rather than using network retries to mask genuine parsing errors.

In Article 7, pdfManager.initDocument() internally passes through ensureDoc multiple times, and ensureDoc ultimately reuses this same ensure logic, so missing chunks during document initialization follow the same path.

Lines 329-441: Aligning the Byte Range to 64KB Chunks

requestRange(begin, end) first converts the range into chunk numbers:

end = Math.min(end, 22491828);
const beginChunk = Math.floor(begin / 65536);
const endChunk = Math.floor((end - 1) / 65536) + 1;

Therefore, a Range request is not sent using the arbitrary byte count from the exception unchanged; instead, it is aligned outward to 64KB boundaries.

_requestChunks then does three things:

1. Removes chunks that have already been loaded;
2. Uses _requestsByChunk to coalesce concurrent requests, avoiding duplicate downloads of the same chunk;
3. Uses groupChunks to merge consecutive chunks into fewer, larger ranges.

const begin = groupedChunk.beginChunk * 65536;
const end = Math.min(groupedChunk.endChunk * 65536, 22491828);
this.sendRequest(begin, end);

So one HTTP Range request may cover only 64KB or multiple consecutive chunks. If only the last chunk is requested:

begin = 343 * 65536 = 22478848;
end = Math.min(344 * 65536, 22491828) = 22491828;

GetRangeReader: When the HTTP Request Is Actually Sent

Lines 62-314: The Worker Sends a GetRangeReader Stream Message

ChunkedStreamManager.sendRequest(begin, end) calls:

const rangeReader = this.pdfStream.getRangeReader(begin, end);

Here, pdfStream is the worker-side PDFWorkerStream. When creating the range reader, it sends:

const readableStream = msgHandler.sendWithStream("GetRangeReader", {
  begin,
  end,
});
this._reader = readableStream.getReader();

There is still no new HTTP request at this point. GetRangeReader merely requests a range reader across threads; the main thread decides whether to access the network.

Lines 46-2725: The Main Thread First Checks Whether the Full Stream Already Covers the Range

The main thread's GetRangeReader handler calls the base class method:

const rangeReader = this.#networkStream.getRangeReader(data.begin, data.end);

The first part of the BasePDFStream.getRangeReader logic is:

if (end <= this._progressiveDataLength) {
  return null;
}

Here, _progressiveDataLength comes from the main thread's PDFFetchStreamReader._loaded and represents the number of bytes of the full response already downloaded to the main thread.

If [begin, end) is entirely covered, the data will arrive through the full stream even if it has not yet been fully delivered to the worker, so there is no need for another HTTP Range request. The main thread handles null as follows:

if (!rangeReader) {
  sink.close();
  return;
}

The worker's range reader then reads done = true, chunks.length === 0; because the demo has disableAutoFetch = true, sendRequest returns immediately and waits for the progressive stream to supply the missing data.

This is the first duplicate-prevention check: data already downloaded by the main thread is not requested again through Range.

Lines 148-206: Add the Range Header Only When the Range Is Not Covered

If end > _progressiveDataLength, the main thread creates a PDFFetchStreamRangeReader:

const headers = new Headers(stream.headers);
headers.append("Range", `bytes=${begin}-${end - 1}`);
fetchUrl(url, headers, withCredentials, this._abortController);

Internally, PDF.js treats end as an exclusive upper bound, whereas HTTP Range uses an inclusive range, so the request header uses end - 1.

Taking the first chunk as an example:

GET /PDF32000_2008.pdf
Range: bytes=0-65535

The demo server actually returns:

HTTP/2 206
content-length: 65536
content-range: bytes 0-65535/22491828

For the last chunk, the corresponding request header is:

Range: bytes=22478848-22491827

The range reader also compares the final origin of this response against the origin recorded for the full response, preventing byte offset semantics from changing after a redirect to a different origin.

Lines 61-2744: Range Bytes Return to the Worker Through the Stream Channel

The main thread similarly reads the range reader through sink.onPull:

sink.onPull = () => {
  rangeReader.read().then(({ value, done }) => {
    if (done) {
      sink.close();
      return;
    }
    sink.enqueue(new Uint8Array(value), 1, [value]);
  });
};

The worker's ChunkedStreamManager.sendRequest keeps reading until done and combines the response, which may be split across multiple frames:

const data = arrayBuffersToBytes(chunks);
this.onReceiveData({ chunk: data.buffer, begin });

ChunkedStream then validates the offset, writes to the shared container, and registers the chunk:

this.bytes.set(new Uint8Array(chunk), begin);
this._loadedChunks.add(curChunk);

The promise waiting for this range resolves only after all required chunks have arrived. ensure from Step 9 then retries the original parsing operation; this time ensureRange succeeds and parsing continues.

Because the demo has disableAutoFetch = true, receiving a chunk does not trigger automatic prefetching of the next missing chunk. The next Range request is still triggered by the parser's next actual missing chunk.

Three Layers of Deduplication Let the Two Channels Run Safely in Parallel

Running the progressive stream and Range requests in parallel seems simple, but avoiding duplicate downloads requires three layers of checks:

The complete cycle can be condensed to:

The parser reads missing bytes
  → MissingDataException(begin, end)
  → Caught by NetworkPdfManager.ensure
  → Align and merge 64KB chunks
  → PDFWorkerStream sends GetRangeReader
  → The main thread checks full-stream coverage
      Covered → sink.close; wait for progressive data
      Not covered → fetch(Range: bytes=begin-end-1)
  → Range data returns to the worker
  → Write to bytes + _loadedChunks
  → The requestRange promise resolves
  → Retry the original parsing operation

Why Document Readiness Does Not Require All 344 Chunks to Download

Article 7 showed that GetDoc requires only pdfManager.initDocument() and document-level metadata reads to succeed. In range mode, these operations require only relevant regions such as the file header, xref, and page tree—not all 344 chunks.

Therefore, the demo can reach the following state:

The full stream continues downloading sequentially in the background
  + The parser fills critical regions through a small number of Range requests
  → GetDoc arrives first
  → loadingTask.promise resolves first
  → The user can call getPage(1) and start rendering
  → The remaining chunks continue to arrive afterward
  → DataLoaded is sent only after everything is loaded

This is exactly why GetDoc and DataLoaded are separate: a document ready to parse and use does not have to mean the complete file has finished downloading.

Summary

This article followed the demo's real responses through network streams and Range requests:

1. GetReader first creates a full PDFFetchStreamReader and sends an ordinary GET without a Range header;
2. The response provides content-length: 22491828 and accept-ranges: bytes, and all five checks pass;
3. The demo supports both streaming and range, so the full stream is not cancelled;
4. The worker creates a NetworkPdfManager and splits the file into 344 chunks of 64KB;
5. disableAutoFetch becomes true because streaming is enabled, avoiding duplicate prefetching alongside the progressive data supply;
6. The progressive full stream and Range data write to the same ChunkedStream, sharing bytes and _loadedChunks;
7. When the parser encounters a missing chunk, it throws MissingDataException, and NetworkPdfManager.ensure retries after requesting the data;
8. The missing byte range is first aligned to chunks, then deduplicated and merged into consecutive ranges;
9. The main thread creates a PDFFetchStreamRangeReader only for ranges not yet covered by the full stream, adding Range: bytes=begin-end-1;
10. Parsing is retried once the Range data has arrived, so GetDoc does not need to wait for the entire file to download.

At this point, all four "heavyweight players" deferred in Article 2 have been explored through the demo: PDFWorker, MessageHandler, WorkerTransport, and the network stream's range request strategy. Article 10 continues down Article 5's rendering chain to examine CanvasGraphics, which consumes the operatorList.

StreamPDF design principle: anything that can be handled ahead of time is absolutely not deferred to parse time; the server solves all performance problems once. The browser only fetches and renders the data it must.
