PDF.js Source Walkthrough: jpx_stream

Introduction

The previous dozen articles all covered filters: Flate, LZW, ASCIIHex, ASCII85, RunLength, Brotli, Predictor. They share one rhythm — implement readBlock, produce a small slice of bytes each time, and let the read loop in DecodeStream stitch the slices into continuous data. The input may arrive in network chunks, and the decoder only cares about the current window.

From this article on we enter the image decoding layer. Image codecs are fundamentally different from general compression: the codestreams of JPEG, JPEG 2000, JBIG2 and CCITT are organised by whole image or whole row, and there are dependencies between blocks, between rows, and between wavelet levels. They cannot be cut anywhere and decoded independently for the first few bytes the way Deflate can. PDF.js therefore unifies the outlet of these streams into a single decodeImage call instead of letting them emit bytes block by block.

The first article in this layer looks at JpxStream in src/core/jpx_stream.js (68 lines). It handles JPEG 2000, which is the /JPXDecode filter in PDF. JPEG 2000 is defined by ISO/IEC 15444 and has been supported since PDF 1.5; it compresses continuous-tone photographs as well as bi-level scans, and it allows an alpha channel to be carried inside the codestream (SMaskInData), which makes it common in medical imaging, maps and high-quality scanned PDFs. CCITT fax decoding belongs to the same layer (covered in the next article); both produce the whole pixel image in one decodeImage, and they differ only in how bytes are fetched and where the parameters come from.

The entry point is Parser.makeFilter:

        case "JPX":
        case "JPXDecode":
          return new JpxStream(stream, maybeLength);

Note that only two arguments are passed here, and DecodeParms is not forwarded. The DCT and CCITT constructors both accept params; JPX does not. The reason is expanded in the section "Where Decode Parameters Come From": the decoding options JPEG 2000 actually needs depend on the image dictionary and the render size rather than on the filter dictionary, so PDFImage prepares them one layer up and passes them in through decoderOptions.

In one sentence, its job is: take the complete upstream codestream, hand it to the singleton JpxImage for asynchronous decoding into a pixel buffer, and write that result straight into the output of DecodeStream.

Module Overview

Without the copyright header and imports, jpx_stream.js is only a little over forty lines, and it splits into five blocks:

Where it sits in the chain:

XObject dictionary /Filter /JPXDecode
  → Parser.makeFilter
  → JpxStream(stream, maybeLength)
  → PDFImage reads the dictionary, builds decoderOptions
  → DecodeStream.getImageData
  → JpxStream.decodeImage
  → JpxImage.instance.decode (OpenJPEG WASM)
  → pixel buffer
  → PDFImage / ImageResizer / main thread

Compared with traditional filters, the biggest difference is that there is no readBlock. The synchronous read contract of DecodeStream is deliberately abandoned here and replaced with the asynchronous contract of decodeImage.

Whole-Image Decoding: Why There Is No readBlock

The DecodeStream base class defines readBlock as an abstract method that subclasses must implement:

  readBlock() {
    unreachable("Abstract method `readBlock` called");
  }

Flate and LZW both override it. JpxStream does not, because it cannot satisfy the semantics of "read a chunk, decode a chunk". A JPEG 2000 codestream is made of multiple tiles, multiple resolution levels and arithmetic coding passes; the decoder must have the complete codestream (at least the whole tile-part) before it can determine the pixels of an image. Forcing a chunked split would only make the decoder re-initialize repeatedly, or produce an incomplete image.

So the call path switches to DecodeStream.getImageData:

  async getImageData(length, decoderOptions) {
    if (!this.canAsyncDecodeImageFromBuffer) {
      return this.isAsyncDecoder
        ? this.decodeImage(null, length, decoderOptions)
        : this.getBytes(length, decoderOptions);
    }
    const data = await this.stream.asyncGetBytes();
    return this.decodeImage(data, length, decoderOptions);
  }

This base-class snippet splits image streams into three cases:

The two capability declarations of JpxStream decide that it takes the third row:

  get isAsyncDecoder() {
    return true;
  }

  get canAsyncDecodeImageFromBuffer() {
    return this.stream.isAsync;
  }

isAsyncDecoder means "this decoder is itself asynchronous"; canAsyncDecodeImageFromBuffer means "the whole buffer can be fetched asynchronously from the underlying stream first". They are not the same thing: the former describes the decoder, the latter describes the data source. JpxStream delegates the latter to this.stream.isAsync, so:

• When the upstream is a ChunkedStream (a network PDF), isAsync is true, the base class first awaits this.stream.asyncGetBytes() to download the whole image, then calls decodeImage(data, ...).
• When the upstream is an ordinary Stream (memory or a local file), isAsync is false, the base class calls decodeImage(null, ...), and bytes ||= this.bytes inside decodeImage fetches the codestream synchronously.

Design note: canAsyncDecodeImageFromBuffer makes the byte-fetching strategy follow the data source instead of being hard-coded in the decoder. The same JpxStream prefetches asynchronously on a network stream and reads synchronously on a memory stream, without changing a single line of decoding logic.

Construction and bytes: Lazily Caching the Whole Codestream

The constructor Method

class JpxStream extends DecodeStream {
  constructor(stream, maybeLength) {
    super(maybeLength);

    this.stream = stream;
    this.dict = stream.dict;
    this.maybeLength = maybeLength;
  }

The constructor does only three things:

this.dict = stream.dict is used instead of taking a separate constructor parameter because a filter chain always shares one dictionary: no matter how many layers of Flate or Predictor are stacked in between, the outermost /Width and /Height still describe the final image. In PDF.js, JPX is usually the last layer of the filter chain, but it follows the same convention.

maybeLength is stored separately. The base class only keeps it as _rawMinBufferLength for buffer growth, while bytes needs the original value to decide how many bytes to request from the upstream; null and a concrete number mean different things, and the value cannot be reconstructed from the base class's power-of-two capacity.

The bytes Method

  get bytes() {
    // If `this.maybeLength` is null, we'll get the entire stream.
    return shadow(this, "bytes", this.stream.getBytes(this.maybeLength));
  }

What shadow does is write the getter's first result directly onto the instance as a property, so later accesses skip the function body. For a complete image that only needs to be read once, this avoids both repeated byte fetches and repeated allocations.

The value of maybeLength determines the read range:

PDF's /Length is sometimes unreliable, especially in incrementally updated or damaged files; falling back to "read everything" when maybeLength is null is the safer option. Note that no length validation happens here: whatever is fetched gets decoded, and the real validity checks live inside JpxImage.

The ensureBuffer Method

  ensureBuffer(requested) {
    // No-op, since `this.readBlock` will always parse the entire image and
    // directly insert all of its data into `this.buffer`.
  }

This is an empty implementation; the requested parameter is completely unused. Its presence is a contract declaration: JpxStream will not grow its buffer through the base class's geometric expansion, because decodeImage assigns the decoding result to this.buffer in one shot.

From the perspective of DecodeStream.getBytes, this empty implementation actually means "do not take the synchronous path": getBytes first calls ensureBuffer and then calls readBlock in a loop; JpxStream has no readBlock, so the synchronous path is bound to hit the base class's unreachable. The class can therefore only be consumed through getImageData, and the empty ensureBuffer cooperates with this narrowed contract.

Design note: An empty implementation is not code saved; it is an explicit denial of one base-class capability. DecodeStream makes "buffer growth plus chunked reading" the default template, and image streams use an empty ensureBuffer and a missing readBlock to tell the reader: the template does not apply here, use the image-specific entry point.

decodeImage: Asynchronous Whole-Image Decoding

The decodeImage Method

  async decodeImage(bytes, _length, decoderOptions) {
    if (this.eof) {
      return this.buffer;
    }
    bytes ||= this.bytes;
    this.buffer = await JpxImage.instance.decode(bytes, decoderOptions);
    this.bufferLength = this.buffer.length;
    this.eof = true;

    return this.buffer;
  }

Line by line:

The third parameter decoderOptions is forwarded as-is, while _length is ignored. This trade-off is essential: the output size of JPEG 2000 is determined by the SIZ marker segment in the codestream header; /Width and /Height in the PDF dictionary are only used for layout and validation. Pre-allocating or truncating according to _length would actually corrupt the image.

bytes ||= this.bytes uses logical-or assignment, so it only falls back when bytes is null or undefined. An empty Uint8Array is truthy and is not replaced, so a zero-length codestream is passed to the decoder as-is and produces an explicit decoding error instead of being silently swapped for upstream data.

JpxImage.instance

The entry point of JpxImage is a singleton:

class JpxImage extends WasmImage {
  _filename = "openjpeg.wasm";

  static get instance() {
    return shadow(this, "instance", new JpxImage(/* trackInstance = */ true));
  }

instance is cached through shadow, so the whole Worker shares one JpxImage. That means the OpenJPEG WASM module is initialized only once, at the cost of writing the codestream into the module heap and reading the result back out on every decode. The actual method body does three things:

const size = bytes.length;
ptr = module._malloc(size);
module.writeArrayToMemory(bytes, ptr);
const ret = module._jp2_decode(
  ptr,
  size,
  numComponents > 0 ? numComponents : 0,
  !!isIndexedColormap,
  !!smaskInData,
  reducePower,
);

_malloc reserves heap space the size of the codestream, writeArrayToMemory copies the JS Uint8Array into it, and _jp2_decode performs entropy decoding, dequantization, the inverse wavelet transform and color transformation inside WASM. The finally block always calls _free, so memory does not leak even when decoding throws.

The returned imageData is detached from the module (module.imageData = null), so the next decode cannot read a stale result.

Design note: The singleton reuses the module, not the state. Every call still allocates, copies and releases its own codestream, and the output is detached from the module. That saves repeated initialization without letting two decodes contaminate each other.

Where Decode Parameters Come From

JpxStream never parses /DecodeParms itself, and decoderOptions do not come from the filter chain. The real construction happens in PDFImage:

this.jpxDecoderOptions = {
  numComponents: 0,
  isIndexedColormap: false,
  smaskInData: dict.get('SMaskInData') >= 1,
  reducePower,
};

Those four fields are not final after the first pass, though. Once the image color space has been resolved, PDFImage fills in two more fields:

if (this.jpxDecoderOptions) {
  this.jpxDecoderOptions.numComponents = hasColorSpace ? this.numComps : 0;
  // If the jpx image has a color space then it mustn't be used in order
  // to be able to use the color space that comes from the pdf.
  this.jpxDecoderOptions.isIndexedColormap = this.colorSpace.name === 'Indexed';
}

So the final source of each field is:

Specifying numComponents when a color space exists aligns the component count in the codestream with the color space declared by the PDF. JPEG 2000 allows a codestream to carry its own color space, but the PDF specification requires the dictionary's /ColorSpace to win; passing the component count explicitly is the same as telling the decoder "produce output according to the PDF convention", and it prevents ICC information embedded in the codestream from overriding the page resources. isIndexedColormap follows the same idea: indexed color has to be expanded to RGB by the decoder, otherwise the index values handed upward cannot be rendered directly.

smaskInData also affects the choice of color space. When SMaskInData is greater than or equal to 1, PDFImage forces the color space to DeviceRGBA, and when the value is 2 it additionally sets jpxPremultiplied (alpha already premultiplied). That means the same codestream may decode to RGB, RGBA or premultiplied RGBA, and decodeImage needs to know nothing about the differences — it only passes decoderOptions through.

reducePower is one of the most valuable features of JPEG 2000: the inverse wavelet can reconstruct only a lower resolution level instead of decoding at full size and then scaling down. For a 6000 by 8000 scan, dropping one level leaves a quarter of the pixels, and dropping two leaves one sixteenth. The decoder lowers the output resolution by that exponent inside _jp2_decode, and PDFImage shrinks image.width and image.height by 2 ** reducePower rounded up, so later layout stays consistent with the pixel dimensions.

This also explains why Parser.makeFilter does not pass params to JpxStream: the filter dictionary only knows which algorithm is used, not how large the final drawing is. Decoding options depend on the render size, the color space and the alpha requirement, and only PDFImage has all of that information.

isImageStream: A Clear Signal to Callers

JpxStream's last capability declaration is:

  get isImageStream() {
    return true;
  }

This boolean takes no part in decoding, yet it affects two upper-level branches. The base class returns false by default, and only image streams override it to true:

The first one matters most. The content of a page may consist of several streams, and StreamsSequenceStream joins them end to end and parses them as a single content stream. If an image XObject stream were mixed in, the Lexer would read pixel bytes as PDF operators, and the result would inevitably be garbage and exceptions. isImageStream stops this misuse at the first layer:

streams = streams.filter(s => s instanceof BaseStream && !s.isImageStream);

The second appears where page content is assembled:

if (content instanceof BaseStream && !content.isImageStream) {
  if (content.isAsync) {
    const bytes = await content.asyncGetBytes();
    if (bytes) {
      return new Stream(bytes, 0, bytes.length, content.dict);
    }
  }
  return content;
}

Image streams are excluded because they can only be consumed through getImageData, not fetched as bytes and re-wrapped into a Stream the way content streams can. Without this check, JpxStream would be treated as an ordinary content stream, and the subsequent synchronous read would run into the missing readBlock.

Design note: A boolean getter carries a type-marker responsibility, not a behaviour switch. The decoding path is separated by decodeImage, the content-stream path is separated by isImageStream, and the two do not interfere. PDF.js deliberately avoids putting image streams and content streams into one type check.

Comparison with the JPEG Decoder Choice

The mainstream image encodings in PDF take different routes inside PDF.js:

Three conclusions:

1. A synchronous decoder can keep readBlock; an asynchronous one cannot. JpegStream.decodeImage is a synchronous function, so readBlock can simply delegate to it and the old getBytes path still works; JPX decoding has to wait for WASM, cannot fit into a synchronous readBlock, and is therefore narrowed to getImageData.
2. The native fast path is open to JPEG only. JpegStream.getTransferableImage tries ImageDecoder and gets a browser-decoded ImageBitmap directly, skipping pixel decoding inside the Worker; JpxStream has no such method, because browsers generally do not hand JPEG 2000 to ImageDecoder.
3. The location of a parameter is decided by the location of its information. JPEG needs only a ColorTransform hint, so DecodeParms is enough; JPX needs the component count, alpha and a downsampling level, which can only be computed once the image dictionary and the render size are known, so the parameters flow from PDFImage into decodeImage.

Design note: Both are "whole-image decoding", yet JpegStream and JpxStream have different capability boundaries. The criterion is not the encoding format but whether the decoder is synchronous, whether the browser offers a native fast path, and whether the parameters can be determined at the filter layer. The three capability declarations of JpxStream are exactly the result of those three points.

Boundaries, Errors and Idempotence

JpxStream is short, so its edge cases are concentrated in a few spots:

Two details deserve a separate mention.

First, eof is set only after a successful decode. If JpxImage.decode throws, buffer is not assigned and eof is still false, so the next call tries again. For network streams this provides a retry opportunity; for corrupt files the error reproduces reliably and is not masked by the previous failure state.

Second, ignoring _length is not an oversight. When PDFImage computes length it uses an estimate of width times height times components, whereas the actual JPX output may be RGBA, may be downsampled, or may even carry an extra channel because of SMaskInData. Only the codestream itself can guarantee that bufferLength corresponds one to one with the real pixels.

Design note: Error handling does one thing only — it does not set eof — and leaves the retry policy to the caller. JpxStream neither swallows exceptions nor returns an empty buffer, because "image decoding failed" and "the image is blank" are entirely different matters at the rendering layer.

Conclusion

JpxStream is the JPEG 2000 whole-image decoding adapter of PDF.js: it takes the complete upstream codestream, hands it together with the decoding options prepared above to OpenJPEG WASM, and writes the pixel buffer as the output of DecodeStream. It does not implement readBlock, the decoding path does not rely on incremental buffer growth, and all of its capabilities revolve around a single asynchronous decode.

Where It Sits in the Chain

In one sentence: Parser creates the stream, PDFImage prepares the parameters, DecodeStream.getImageData decides how bytes are fetched, decodeImage waits for WASM to finish the whole image, and the rendering layer only receives pixels.

Five Design Principles

1. Image streams do not implement readBlock. A whole-image encoding cannot be decoded independently block by block, so the synchronous read contract fails here; the capability is narrowed to getImageData, and decodeImage does all the work.
2. Bytes are lazy and fetched once. bytes is cached with shadow, and falls back to reading everything when maybeLength is null; on network streams, canAsyncDecodeImageFromBuffer prefetches asynchronously ahead of time.
3. Parameters are layered. The filter layer only creates the stream; decoding options are produced by PDFImage, which holds the image dictionary and the render size, and are forwarded as decoderOptions, so lower layers never have to guess the intentions of upper layers.
4. A singleton is reused; each decode is isolated. JpxImage.instance shares the WASM module, while every decode allocates and releases its own codestream memory and detaches the output promptly, avoiding contamination between calls.
5. The codestream is the authority on output. _length is ignored and bufferLength is filled with the real pixel length, so both downsampling and in-codestream alpha are reflected correctly downstream.

The next article looks at ccitt_stream.js in the same layer. It is also a whole-image decoder, but it moves the asynchronous byte fetching inside decodeImage, and it flattens the seven fax-encoding parameters from the dictionary into one plain object — two routes that form the two answers to "who decides where the bytes come from" in the image decoding layer.
