PDF.js Deep Dive from Demo 1: Rendering a PDF with a Custom Viewer

Introduction

In our previous series of articles, we explored the architecture of PDF.js, as well as technical topics such as the rendering layer and message communication. However, while writing those articles, we identified a few problems:

• The articles could not be connected to one another and failed to form a complete knowledge system.
• They could not be mapped back to the PDF.js source code, so following along carried a heavy mental burden.

Therefore, we decided to start a new series that begins with demo code and gradually follows the call chain deep into the internals of PDF.js. We will explain the principles behind the code from two perspectives:

• Demo interpretation: case-by-case interpretation, linked from shallow to deep, exploring in depth.
• Repository interpretation: generalized interpretation that can be read in chunks, each standing on its own as an article.

Come on, let's start from the beginning.

Rendering a PDF with a Custom Viewer

Let's try building a minimal custom viewer to render a PDF, then follow each line of code into the internals of PDF.js. As we follow along, we will substitute variable values into the code to make the execution flow easier to understand.

import * as pdfjsLib from 'https://cdn.jsdelivr.net/npm/pdfjs-dist@6.3.289/build/pdf.mjs';
pdfjsLib.GlobalWorkerOptions.workerSrc =
  'https://cdn.jsdelivr.net/npm/pdfjs-dist@6.3.289/build/pdf.worker.mjs';
const loadingTask = pdfjsLib.getDocument({
  url: 'https://assets.streampdf.com/PDF32000_2008.pdf',
});
const pdf = await loadingTask.promise;
// Get the rendering data of the first page
const page = await pdf.getPage(1);
// Get the viewport data of the first page
const viewport = page.getViewport({ scale: 0.5 });
// Get the canvas onto which we will render
const canvas = document.getElementById('canvas-id');
const context = canvas.getContext('2d');

// Match the canvas dimensions to the PDF viewport size
canvas.width = Math.floor(viewport.width);
canvas.height = Math.floor(viewport.height);
canvas.style.width = Math.floor(viewport.width) + 'px';
canvas.style.height = Math.floor(viewport.height) + 'px';

// Prepare the rendering parameters
const renderContext = {
  canvasContext: context,
  viewport,
};

// Call the render method to perform the actual rendering, awaiting its completion
await page.render(renderContext);

demo: https://streampdf.com/blog/demos/a-simple-pdf-render-demo.html

Lines 1-3: Configure the Worker file path

Import the entry file of the PDF.js library and set the path of the Worker file.

This means that when using PDF.js, we can even completely replace the Worker with our own, as long as it follows the interface specification.

Here we set it to the default Worker file path:

GlobalWorkerOptions.workerSrc = https://cdn.jsdelivr.net/npm/pdfjs-dist@6.3.289/build/pdf.worker.mjs

Lines 4-7: Load the PDF document

Call the getDocument method to load the PDF document, passing in an object parameter:

• src: the URL of the PDF document. The value is https://assets.streampdf.com/PDF32000_2008.pdf.

The getDocument method returns a Promise that resolves to a PDF document object once the document has finished loading.

const loadingTask = pdfjsLib.getDocument(...) is a synchronous call: click to view the call.

loadingTask.promise is a getter that returns a Promise created by the Promise.withResolvers() method.

Here we await loadingTask.promise to wait for the PDF document to finish loading and assign it to the pdf variable.

Lines 8-10: Get the first page of the PDF document

Once the document has been initialized, we can call the getPage method to get the rendering data of the first page.

The getPage method returns a Promise that resolves to a page object once the page data has finished loading.

const page = await pdf.getPage(1); is an asynchronous call: click to view the call.

After the first page's data has finished loading, it is assigned to the page variable.

Lines 11-14: Get the viewport data of the first page

Once the page data has loaded, we can call the getViewport method to get the viewport data of the first page.

const viewport = page.getViewport({ scale: 0.5 }); is a synchronous call: click to view the call.

Get the viewport data of the first page, passing in an object parameter:

• scale: the scale factor. The value is 0.5.

The returned viewport is an object containing the width and height of the viewport. Its value is:

{
  width: 297.5,
  height: 421,
  // others, not used here, omitted for now...
}

It is assigned to the viewport variable.

Lines 15-18: Get the canvas onto which we will render

After obtaining the viewport variable, match the canvas's width and height to the PDF viewport size.

canvas.width = 297; // Math.floor(viewport.width);
canvas.height = 421; // Math.floor(viewport.height);

Also set the canvas's CSS width and height to the PDF viewport size.

canvas.style.width = 297 + 'px'; // Math.floor(viewport.width) + 'px';
canvas.style.height = 421 + 'px'; // Math.floor(viewport.height) + 'px';

Why do we need to set the canvas's CSS width and height? The canvas's width and height attributes control the pixel dimensions of the canvas, while the CSS width and height are the dimensions at which the canvas is displayed on the page. In general, these two are the same. But on high-resolution screens, they differ. For example, when window.devicePixelRatio is 2, the canvas's pixel dimensions should be set to 594 by 842, while the CSS width and height remain 297 by 421, to prevent blurry rendering.

Lines 19-22: Render the first page

Once the canvas is ready, we can call the render method to render the first page.

Prepare the canvas context, viewport data, and rendering parameters so that we can call the render method.

await page.render(renderContext); is an asynchronous call: click to view the call.

At this point, the code execution is complete.

Summary

In this chapter, we followed a custom viewer to render the first page of a PDF file.

The biggest difference from other articles is that we substituted variable values into the chain of code being analyzed, so that different execution paths can be determined. Different files and analysis articles lead into different branch paths, making reading the article feel like debugging the code.

We hope this brings you a different kind of source code reading experience.

happy coding!
